Preamp Type

Solid-State Preamp

Wattage

300 Watts @ 4 Ohms / 150 Watts @ 8 Ohms

Channels/Inputs

2 Channels / Ch 1 = Selectable XLR w/P-12 Phantom or 1/4", Ch 2 = 1/4"

Drive Dynamics Control

n/a

Graphic Eq Reverb Fx Solo

Variable Hi-Pass Filter (40Hz to 200Hz), Fully Active 4-Band EQ Controls (+/- 12dB of Bass, Low-Mid, High-Mid & Treble) with Sweepable (variable) Low-Mid (150Hz-1800Hz) & High-Mid (300Hz-5000Hz) Frequency Controls

Fx Boost Solo

3 Internal Effects Options (Chorus+Reverb, Room or Hall Reverb) with 3 Parameter Controls, Parallel FX Loop (for external FX)

Foot switchable Functions

External Switching Jacks for Channel Mutes and Internal FX Bypass (Footswitches Sold Seperately)

Speakers Impedance

2 - 8", 8 Ohm Rosette 150 Speakers & 1 - HF Dome Tweeter / Total Load = 4 Ohms

Weight

30 Lbs.

Dimensions

13.25" H x 18" W x 12.25" D

Available Formats

1x10 (8 Ohm) or 2x8 (4 Ohm) Combos

Amp Type

Solid-State Preamp & Class D Power Amp

Preamp Tubes

n/a

Power Amp Tubes

Class D Power Amp

Wattages Quick Reference

300 Watts @ 4 Ohms / 150 Watts @ 8 Ohms

Power Amp Details Class Wattage

Light-Weight, Compact Class D Power Amp with Protection & Limit LED Indicators

Reverb Effects Bypass Options

3 Internal Effects Options (Chorus+Reverb, Room or Hall Reverb) with Front Panel Status LED, 3 Parameter Controls & Optional On/Off Footswitch Control (footswitch sold separately)

Effects Loop Bypass Options

Parallel FX Loop (for extrenal FX)

Global Solo Level Control

n/a

External Switching Jack Options And/or Midi

External Switching Jacks for Channel Mutes and Internal FX Bypass (Footswitches Sold Seperately)

Speaker Outputs

Two 1/4" Output Jack (4 Ohm Minimum)

Cabinet Simulation Direct Live recording Output

3 Balanced XLR Direct Line Out Options: Channel 1 Only with Pre/Post, Line/Mic & Ground Lift Switches, Channel 2 Only with Pre/Post, Line/Mic & Ground Lift Switches & Channel 1 & 2 (Post EQ & FX Only) with Line/Mic & Ground Lift Switches

Slave Output

n/a

Extra Features

Headphone Output and Auxiliary Input

Footswitch

Optional (Sold Seperately) - Channel Mutes and/or Internal FX Bypass Footswitches

Slip Cover

Included - Fitted Slip Cover

Cabinet Material

Marine Grade, Baltic Birch

Standard Finish Options (No Extra Cost)

Choice of British Tan Bronco Vinyl, Black Taurus or Black Bronco Vinyl with Cream/Tan Weave or Black Jute Grille & Brown or Black Corners & Handle

Custom Finish Options

See Custom Finish Gallery

Speakers Impedance

2 - 8", 8 Ohm Rosette 150 Speakers & 1 - HF Dome Tweeter / Total Load = 4 Ohms

Casters

n/a

Extra Features

Twist-Lift Adjustable Tilt-Back System

Weight

30 Lbs.

Height

13.25"

Width

18"

Depth

12.25"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
