Wattage

Full Power (40W Clean/60W Max) or Half Power (20W Clean/28W Max) Selectable (Global)

Channels & Modes

2 Channels / 3 Mode Channel Cloning™

Mode Voicings styles

Ch. 1 = Clean, Drive or HI (Channel Cloning™) Ch. 2 = Clean, Drive or HI (Channel Cloning™)

Graphic Eq Reverb Fx Solo

Reverb & FX Loop

Foot switchable Functions

Ch. 1/2

Speakers Impedance

1 - 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms

Weight

45 Lbs.

Dimensions

17 7/8" H x 22 3/4" W x 10 1/8" D

Available Formats

Head & 1x12 Combo

Amp Type

Tube

Rectifier Type

Silicon Diodes

Rectifier Tubes

n/a

Variac PowerSwitch

n/a

Preamp Tubes

5x Mesa 12AX7

Power Amp Tubes

2x Mesa 6L6

Maintenance Free Fixed Bias

Yes

Wattages Quick Reference

40 Watts Clean/60 Watts Max or 20 Watts Clean/28 Watts Max via single, global Full/Half Power Switch - See Power Amp Details for more information

Built In Power Amp Attenuation

n/a

Power Amp Details Class Wattage

MESA's proprietary Dyna-Watt™, Class A/B Power Amp with a single, global Full/Half Power Switch - Each setting features a different wiring configurations, Pentode or Triode respectively. Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 20 (Clean)/28 (Max) Watts or; 2 tubes operating in Class A/B Pentode for maximum power, punch and clarity, producing 40 (Clean)/60 (Max) Watts. More information on Dyna-Watt Power can be found in the Owners Manual, which is available in the Support Section of this website.

Number Of Style Modes

Three

Number Of Style Modes Per Channel

Three (Channel Cloning™)

Channel Controls

Each Channel features Independent 3-Position Channel Cloning™ Mode Switch, Gain, Treble, Mid, Bass, Presence, Reverb, and Master

Graphic Eq And/or Contour

n/a

Reverb Effects Bypass Options

All-Tube, Spring Reverb with Independent Channel Controls

Effects Loop Bypass Options

Fully Buffered Series FX Loop

Global Output Level Control

n/a

Global Solo Level Control

n/a

True Bypass Options

n/a

External Switching Jack Options And/or Midi

External Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold seperately)

Speaker Outputs

One 8 Ohm and Two 4 Ohm

Cabinet Simulation Direct Live recording Output

n/a

Internal Amp Load For SpeakerLess Performance

n/a

Headphone Output

n/a

Slave Output

n/a

Extra Features

Reverb Controls located on front panel

Footswitch

Included - 1 Button Footswitch (Ch. 1/2)

Slip Cover

Included - Fitted Slip Cover

Cabinet Material

Marine Grade, Baltic Birch

Standard Finish Options (No Extra Cost)

Choice of Black Bronco or Black Taurus Vinyl with Tinsel or Black Jute Grille

Custom Finish Options

See Custom Finish Gallery

Speakers Impedance

1 - 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms

Casters

Optional - Track-Loc™ Removable Casters

Extra Features

Vintage-Inspired Size for Tone & Portability

Weight

45 Lbs.

Height

17 7/8"

Width

22 3/4"

Depth

10 1/8"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
