Wattage

Multi-Watt™ 25, 45, or 90 (Channel Assignable)

Channels & Modes

3 Channels / 9 Modes

Mode Voicings styles

Ch. 1 = Clean, Fat, or Crunch Ch. 2 = Fat, Crunch, or Mark VII™ Ch. 3 = Mark IIB™, Mark IIC+™, or Mark IV™

Graphic Eq Reverb Fx Solo

Graphic EQ, Reverb, FX Loop, CabClone IR

Foot switchable Functions

Ch. 1, 2, 3, Reverb, FX Loop, & Graphic EQ

Speakers Impedance

1 - 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms

Weight

58 Lbs. / 26.31 kg.

Dimensions

18 1/4" H x 18 3/4" W x 11 1/2” D 46.36 cm H x 47.63 cm W x 29.21 cm D

Available Formats

Head, Rackmount Head, & 1x12 Combo

Amp Type

Tube

Rectifier Type

Silicon Diodes

Rectifier Tubes

n/a

Variac PowerSwitch

n/a

Preamp Tubes

5x Mesa 12AX7

Power Amp Tubes

4x Mesa 6L6 (or EL34)

Maintenance Free Fixed Bias

Yes

Wattages Quick Reference

25, 45, or 90 Watts - Channel Assignable - See Power Amp Details for more information

Built In Power Amp Attenuation

n/a

Power Amp Details Class Wattage

MESA/Boogie's exclusive Simul-Class™ Power Amp featuring Multi-Watt™ (Patent 7,602,927) with Incremental Wattage Reduction (Patent 9,917,560) which provide three power and two operating-class options that are channel assignable via 25/45/90 Watt Power Switches: Choose 2 power tubes operating in Class A Triode, producing 25 Watts - 2 tubes running in Class A Pentode, producing 45 Watts, or 4 tubes running in MESA/Boogie’s legendary Simul-Class Power that blends the best of Class A and Class A/B simultaneously to produce 90 Watts of pure tonal magic.

Number Of Style Modes

Nine

Number Of Style Modes Per Channel

Three

Channel Controls

Each Channel features: Independent 3-Position Style Mode Switch, Graphic EQ Assignment Switch (On, Off or Footswitchable), Patented Watt Multi-Watt™ 90/45/25 Power Amp Switch, Gain, Treble, Mid, Bass, Presence, & Master Controls, Reverb (Footswitchable), and an 8-Position CabClone IR Select Control (back-panel)

Graphic Eq And/or Contour

Selectable 5-Band Graphic EQ (Footswitchable, Channel Assignable, or Off)

Reverb Effects Bypass Options

Footswitchable, All-Tube, Long Spring Reverb with Independent Channel Controls

Effects Loop Bypass Options

Tube-Buffered FX Loop (Footswitchable)

Global Output Level Control

n/a

Global Solo Level Control

n/a

True Bypass Options

n/a

External Switching Jack Options And/or Midi

MIDI Switchable/Programmable via Control Change and Program Change messages, with 256 Preset Location (MIDI IN, MIDI Thru/Out, MIDI Channel, & Store Switches) – Controls Channels 1, 2, 3, Reverb, FX Loop, & Graphic EQ

Speaker Outputs

Two 8 Ohm and Two 4 Ohm

Cabinet Simulation Direct Live recording Output

Built-in, channel assignable, MESA CabClone™ IR Cab Simulator featuring 8 MESA Cabinet IRs, USB Connection for IR transfers, Internal Amp Load for cabinet-free use, Input Level Control, IR Balanced XLR Direct Output, (Dry) Line Output (Uncompensated, +4db Direct Line Output for external cab sim/IR use, Re-Amping, etc.), Headphone Output, IR Output Level Control & Ground/Lift Switch

Internal Amp Load For SpeakerLess Performance

Yes (see Cabinet Simulation for more information)

Headphone Output

Yes (see Cabinet Simulation for more information)

Slave Output

n/a

Extra Features

n/a

Footswitch

Included - 3x3 - 6 Button Footswitch (Bottom Row: Ch. 1, Ch. 2, & Ch. 3 - Top Row: Reverb, FX Loop, & Graphic EQ)

Slip Cover

Included - Fitted Slipcover

Cabinet Material

Marine Grade, Baltic Birch

Standard Finish Options (No Extra Cost)

Black Bronco Vinyl, Black Jute Grille, Black Handle & Corners

Custom Finish Options

See Custom Finish Gallery

Speakers Impedance

1 - 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms

Casters

n/a

Extra Features

n/a

Weight

58 Lbs. / 26.31 kg.

Height

18 1/4" / 46.36 cm

Width

18 3/4" / 47.63 cm

Depth

11 1/2" / 29.21 cm

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
