Wattage

25 or 10 Watt Selectable (Global)

Channels & Modes

2 Channels / 3 Mode Channel Cloning™

Mode Voicings styles

2 Channels / 3 Mode Channel Cloning™

Graphic Eq Reverb Fx Solo

FX Loop

Foot switchable Functions

Ch. 1/2

Speakers Impedance

n/a

Weight

19 lb. / 8.62 kg.

Dimensions

8 1/2" H x 18 3/8" W x 10" D / 21.59 cm H x 46.67 cm W x 25.40 cm D

Available Formats

Head & 1x12 Combo

Amp Type

Tube

Rectifier Type

Silicon Diodes

Rectifier Tubes

n/a

Variac PowerSwitch

n/a

Preamp Tubes

5x 12AX7

Power Amp Tubes

2x EL-84

Maintenance Free Fixed Bias

Yes

Wattages Quick Reference

25 or 10 Watt Selectable (Global)

Built In Power Amp Attenuation

n/a

Power Amp Details Class Wattage

Class A/B Power with global 25/10 Power Switch - Provides two power options: Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 10 Watts or 2 tubes operating in Mesa's proprietary Dyna-Watt™ Class A/B Pentode for maximum power, punch, and clarity, producing 25 Watts

Number Of Style Modes

Three

Number Of Style Modes Per Channel

Three (Channel Cloning™)

Channel Controls

Each Channel features Independent, 3-Position Style Mode Switch, Gain, Treble, Mid, Bass, Presence, Master, and 8-Position CabClone IR Select (back-panel) Controls

Graphic Eq And/or Contour

n/a

Reverb Effects Bypass Options

n/a

Effects Loop Bypass Options

Tube-Driven, Series FX Loop

Global Output Level Control

n/a

Global Solo Level Control

n/a

True Bypass Options

n/a

External Switching Jack Options And/or Midi

n/a

Speaker Outputs

One 8 Ohm and Two 4 Ohm

Cabinet Simulation Direct Live recording Output

Built-in, channel assignable, MESA CabClone™ IR Cab Simulator featuring 8 MESA Cabinet IRs, USB Connection for IR transfers, Internal Amp Load for cabinet-free use, IR Balanced XLR Direct Output, Headphone Output, IR Output Level Control, & Ground/Lift Switch

Internal Amp Load For SpeakerLess Performance

Yes (see Cabinet Simulation for more information)

Headphone Output

Yes (see Cabinet Simulation for more information)

Slave Output

n/a

Extra Features

n/a

Footswitch

Included - 1 Button Footswitch (Ch. 1/2)

Slip Cover

Included - Fitted Slipcover

Cabinet Material

Marine Grade, Baltic Birch

Standard Finish Options (No Extra Cost)

Black Bronco Vinyl, Black Diamond Plate, Black Handle & Corners

Custom Finish Options

See Custom Finish Gallery

Speakers Impedance

n/a

Casters

n/a

Extra Features

n/a

Weight

19 lb. / 8.62 kg.

Height

8 1/2" / 21.59 cm

Width

18 3/8" / 46.67 cm

Depth

10" / 25.40 cm

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
