Wattage

Full Power (98W Clean/112W Max), Half Power (40W Clean/50W Max) or Low Power (22W Clean/30W Max) Selectable (Global)

Channels & Modes

2 Channels / 3 Mode Channel Cloning™

Mode Voicings styles

Ch. 1 = Clean, Drive or HI (Channel Cloning™) Ch. 2 = Clean, Drive or HI (Channel Cloning™)

Graphic Eq Reverb Fx Solo

Reverb & FX Loop

Foot switchable Functions

Ch. 1/2

Speakers Impedance

n/a

Weight

36 Lbs.

Dimensions

9 3/4" H x 22 3/4" W x 9 1/2" D

Available Formats

Head & 1x12 Combo

Amp Type

Tube

Rectifier Type

Silicon Diodes

Rectifier Tubes

n/a

Variac PowerSwitch

n/a

Preamp Tubes

5x Mesa 12AX7

Power Amp Tubes

4x Mesa 6L6

Maintenance Free Fixed Bias

Yes

Wattages Quick Reference

Full Power (98W Clean/112W Max), Half Power (40W Clean/50W Max) or Low Power (22W Clean/30W Max) via single, global Full/Half/Low Power Switch - See Power Amp Details for more information

Built In Power Amp Attenuation

n/a

Power Amp Details Class Wattage

MESA's proprietary Dyna-Watt™, Class A/B Power Amp with a single, global Full/Half/Low Power Switch. Each setting features a different tube count and/or wiring configurations. Full Power Mode utilizes all 4 power tubes, producing 98 (clean)/112 (max). Half Power utilizes 2 power tubes, producing 40 (clean)/50 (max) Watts. Both Full and Half Power Modes operate in Class A/B Pentode for maximum power, punch and clarity. Low Power Mode utilizes 2 tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 22 (clean)/30 (max) Watts. More information on Dyna-Watt Power can be found in the Owners Manual, which is available in the Support Section of this website.

Number Of Style Modes

Three

Number Of Style Modes Per Channel

Three (Channel Cloning™)

Channel Controls

Each Channel features Independent 3-Position Channel Cloning™ Mode Switch, Gain, Treble, Mid, Bass, Presence, Reverb and Master

Graphic Eq And/or Contour

n/a

Reverb Effects Bypass Options

All-Tube, Spring Reverb with Independent Channel Controls

Effects Loop Bypass Options

Fully Buffered Series FX Loop

Global Output Level Control

n/a

Global Solo Level Control

n/a

True Bypass Options

n/a

External Switching Jack Options And/or Midi

External Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold seperately)

Speaker Outputs

One 8 Ohm and Two 4 Ohm

Cabinet Simulation Direct Live recording Output

n/a

Internal Amp Load For SpeakerLess Performance

n/a

Headphone Output

n/a

Slave Output

n/a

Extra Features

Reverb Controls located on front panel

Footswitch

Included - 1 Button Footswitch (Ch. 1/2)

Slip Cover

Included - Fitted Slip Cover

Cabinet Material

Marine Grade, Baltic Birch

Standard Finish Options (No Extra Cost)

Choice of Black Bronco or Black Taurus Vinyl with Tinsel or Black Jute Grille

Custom Finish Options

See Custom Finish Gallery

Speakers Impedance

n/a

Casters

n/a

Extra Features

Vintage-Inspired Size for Tone & Portability

Weight

36 Lbs.

Height

9 3/4"

Width

22 3/4"

Depth

9 1/2"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
