Wattage

Multi-Watt™ 10, 25 or 35 (Channel Assignable)

Channels & Modes

2 Channels / 6 Modes

Mode Voicings styles

Ch. 1 = Clean, Fat or Crunch Ch. 2 = Mark IIC+™, Mark IV™ or Extreme

Graphic Eq Reverb Fx Solo

Graphic EQ, Reverb, FX Loop & Ch. Independent Solo

Foot switchable Functions

Ch. 1/2, EQ, Solo Ch 1 & Solo Ch 2

Speakers Impedance

n/a

Weight

19 Lbs.

Dimensions

7" H x 19 1/8" W x 10 1/4" D

Available Formats

Head, Rackmount & 1x12 Combo

Amp Type

Tube

Rectifier Type

Silicon Diodes

Rectifier Tubes

n/a

Variac PowerSwitch

n/a

Preamp Tubes

6x Mesa 12AX7

Power Amp Tubes

4x Mesa EL-84

Maintenance Free Fixed Bias

Yes

Wattages Quick Reference

10, 25 or 35 Watts - Channel Assignable - See Power Amp Details for more information

Built In Power Amp Attenuation

n/a

Power Amp Details Class Wattage

Mesa's Patented Multi-Watt™ (Patent 7,602,927) Power Amp, featuring Dyna-Watt™ technology, providing three power levels and two wiring configurations (Pentode/Triode) via two 10/25/35 Watt Power Switches: Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 10 Watts or; 2 or 4 tubes operating in Mesa's proprietary Dyna-Watt™ Class A/B Pentode for maximum power, punch and clarity, producing 25 or 35 Watts respectively

Number Of Style Modes

Six

Number Of Style Modes Per Channel

Three

Channel Controls

Each Channel features Independent 3-Position Style Mode Switch, 10/25/35 Watt Multi-Watt™ Switch, Gain, Treble, Mid/Boost* (Ch 1), Mid (Ch 2), Bass, Presence, Reverb (back panel), Master, Footswitchable Channel Independant Solo and Graphic EQ Assignment Switch (On, Off or Footswitchable) - *The Mid/Boost Control on Channel 1 doubles as a standard Mid Control when set between 0 to 5 and turns into a Variable Gain Boost when set from 5 to 10

Graphic Eq And/or Contour

Selectable 5-Band Graphic EQ (Footswitchable, Channel Assignable or Off)

Reverb Effects Bypass Options

All-Tube, Long-Tank Spring Reverb with Independent Channel Controls

Effects Loop Bypass Options

Fully Buffered Series FX Loop

Global Output Level Control

n/a

Global Solo Level Control

Footswitchable, Channel Independent Solo Controls

True Bypass Options

n/a

External Switching Jack Options And/or Midi

n/a

Speaker Outputs

One 8 Ohm and Two 4 Ohm

Cabinet Simulation Direct Live recording Output

Built-in Mesa CabClone™ Cab Simulator with Internal Amp Load & Headphone Output - Featuring Closed Back, Open Back & Vintage Cabinet Simulations, Speaker On/Off and Ground Lift Switches

Internal Amp Load For SpeakerLess Performance

Yes (see Cabinet Simulation for more information)

Headphone Output

Yes (see Cabinet Simulation for more information)

Slave Output

n/a

Extra Features

Larger Transformers than the Mark Five: 25

Footswitch

Included - 4 Button Footswitch (Ch. 1/2, EQ, Solo Ch 1 & Solo Ch 2)

Slip Cover

n/a

Cabinet Material

n/a

Standard Finish Options (No Extra Cost)

n/a

Custom Finish Options

n/a

Speakers Impedance

n/a

Casters

n/a

Extra Features

n/a

Weight

19 Lbs.

Height

7"

Width

19 1/8"

Depth

10 1/4"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
