{{ featureCallout.Title }}
Wattage
Multi-Watt™ 25, 45, or 90 (Channel Assignable)
Channels & Modes
3 Channels / 9 Modes
Mode Voicings styles
Ch. 1 = Clean, Fat, or Crunch Ch. 2 = Fat, Crunch, or Mark VII™ Ch. 3 = Mark IIB™, Mark IIC+™, or Mark IV™
Graphic Eq Reverb Fx Solo
Graphic EQ, Reverb, FX Loop, CabClone IR
Foot switchable Functions
Ch. 1, 2, 3, Reverb, FX Loop, & Graphic EQ
Speakers Impedance
n/a
Weight
40 Lbs. / 18.14 kg.
Dimensions
9 1/4" H x 18 3/4" W x 10 7/8” D 23.50 cm H x 47.63 cm W x 27.62 cm D
Available Formats
Head, Rackmount Head, & 1x12 Combo
Amp Type
Tube
Rectifier Type
Silicon Diodes
Rectifier Tubes
n/a
Variac PowerSwitch
n/a
Preamp Tubes
5x Mesa 12AX7
Power Amp Tubes
4x Mesa 6L6 (or EL34)
Maintenance Free Fixed Bias
Yes
Wattages Quick Reference
25, 45, or 90 Watts - Channel Assignable - See Power Amp Details for more information
Built In Power Amp Attenuation
n/a
Power Amp Details Class Wattage
MESA/Boogie's exclusive Simul-Class™ Power Amp featuring Multi-Watt™ (Patent 7,602,927) with Incremental Wattage Reduction (Patent 9,917,560) which provide three power and two operating-class options that are channel assignable via 25/45/90 Watt Power Switches: Choose 2 power tubes operating in Class A Triode, producing 25 Watts - 2 tubes running in Class A Pentode, producing 45 Watts, or 4 tubes running in MESA/Boogie’s legendary Simul-Class Power that blends the best of Class A and Class A/B simultaneously to produce 90 Watts of pure tonal magic.
Number Of Style Modes
Nine
Number Of Style Modes Per Channel
Three
Channel Controls
Each Channel features: Independent 3-Position Style Mode Switch, Graphic EQ Assignment Switch (On, Off, or Footswitchable), Patented Watt Multi-Watt™ 90/45/25 Power Amp Switch, Gain, Treble, Mid, Bass, Presence, & Master Controls, Reverb (Footswitchable), and an 8-Position CabClone IR Select Control (back-panel)
Graphic Eq And/or Contour
Selectable 5-Band Graphic EQ (Footswitchable, Channel Assignable or Off)
Reverb Effects Bypass Options
Footswitchable, All-Tube, Long Spring Reverb with Independent Channel Controls
Effects Loop Bypass Options
Tube-Buffered FX Loop (Footswitchable)
Global Output Level Control
n/a
Global Solo Level Control
n/a
True Bypass Options
n/a
External Switching Jack Options And/or Midi
MIDI Switchable/Programmable via Control Change and Program Change messages, with 256 Preset Location (MIDI IN, MIDI Thru/Out, MIDI Channel, & Store Switches) – Controls Channels 1, 2, 3, Reverb, FX Loop, & Graphic EQ
Speaker Outputs
Two 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output
Built-in, channel assignable, MESA CabClone™ IR Cab Simulator featuring 8 MESA Cabinet IRs, USB Connection for IR transfers, Internal Amp Load for cabinet-free use, Input Level Control, IR Balanced XLR Direct Output, (Dry) Line Output (Uncompensated, +4db Direct Line Output for external cab sim/IR use, Re-Amping, etc.), Headphone Output, IR Output Level Control, & Ground/Lift Switch
Internal Amp Load For SpeakerLess Performance
Yes (see Cabinet Simulation for more information)
Headphone Output
Yes (see Cabinet Simulation for more information)
Slave Output
n/a
Extra Features
n/a
Footswitch
Included - 3x3 - 6 Button Footswitch (Bottom Row: Ch. 1, Ch. 2, & Ch. 3 - Top Row: Reverb, FX Loop, & Graphic EQ)
Slip Cover
Included - Fitted Slipcover
Cabinet Material
Marine Grade, Baltic Birch
Standard Finish Options (No Extra Cost)
Black Bronco Vinyl, Black Jute Grille, Black Handle & Corners
Custom Finish Options
See Custom Finish Gallery
Speakers Impedance
n/a
Casters
n/a
Extra Features
n/a
Weight
40 Lbs. / 18.14 kg.
Height
9 1/4" / 23.50 cm
Width
18 3/4" / 47.63 cm
Depth
10 7/8" / 27.62 cm
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
