{{ labels['key-features'] }}
-
{{ featureCallout.Title }}
Wattage
Multi-Watt™ 10 or 25 (Channel Assignable)
Channels & Modes
2 Channels / 6 Modes
Mode Voicings styles
Ch. 1 = Clean, Fat or Crunch Ch. 2 = Mark IIC+™, Mark IV™ or Extreme
Graphic Eq Reverb Fx Solo
Graphic EQ, Reverb & FX Loop
Foot switchable Functions
Ch. 1/2 & EQ
Speakers Impedance
n/a
Weight
16.5 Lbs.
Dimensions
8" H x 14" W x 8 3/4" D
Available Formats
Head & 1x10 Combo
Amp Type
Tube
Rectifier Type
Silicon Diodes
Rectifier Tubes
n/a
Variac PowerSwitch
n/a
Preamp Tubes
6x Mesa 12AX7
Power Amp Tubes
2x Mesa EL-84
Maintenance Free Fixed Bias
Yes
Wattages Quick Reference
10 or 25 Watts - Channel Assignable - See Power Amp Details for more information
Built In Power Amp Attenuation
n/a
Power Amp Details Class Wattage
Mesa's Patented Multi-Watt™ (Patent 7,602,927) Power Amp, featuring Dyna-Watt™ technology, providing two power levels, each with different wiring configurations (Pentode/Triode) via two 10/25 Watt Power Switches: Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 10 Watts or; 2 tubes operating in Mesa's proprietary Dyna-Watt™ Class A/B Pentode for maximum power, punch and clarity, producing 25 Watts
Number Of Style Modes
Six
Number Of Style Modes Per Channel
Three
Channel Controls
Each Channel features Independent 3-Position Style Mode Switch, 10/25 Watt Multi-Watt™ Switch, Gain, Treble, Mid/Boost* (Ch 1), Mid (Ch 2), Bass, Presence, Reverb (back panel), Master and Graphic EQ Assignment Switch (On, Off or Footswitchable) - *The Mid/Boost Control on Channel 1 doubles as a standard Mid Control when set between 0 to 5 and turns into a Variable Gain Boost when set from 5 to 10
Graphic Eq And/or Contour
Selectable 5-Band Graphic EQ (Footswitchable, Channel Assignable or Off)
Reverb Effects Bypass Options
All-Tube, Spring Reverb with Independent Channel Controls
Effects Loop Bypass Options
Fully Buffered Series FX Loop
Global Output Level Control
n/a
Global Solo Level Control
n/a
True Bypass Options
n/a
External Switching Jack Options And/or Midi
n/a
Speaker Outputs
One 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output
Built-in Mesa CabClone™ Cab Simulator with Internal Amp Load & Headphone Output - Featuring Closed Back & Open Back Cabinet Simulations, Speaker On/Off and Ground Lift Switches
Internal Amp Load For SpeakerLess Performance
Yes (see Cabinet Simulation for more information)
Headphone Output
Yes (see Cabinet Simulation for more information)
Slave Output
n/a
Extra Features
n/a
Footswitch
Included - 2 Button Footswitch (Ch. 1/2 & EQ)
Slip Cover
Included - Fitted Slip Cover
Cabinet Material
Marine Grade, Baltic Birch
Standard Finish Options (no extra cost)
Black Bronco Vinyl, Black Jute Grille, Black Handle & Corners
Custom Finish Options
See Custom Finish Gallery
Speakers Impedance
n/a
Casters
n/a
Extra Features
n/a
Weight
16.5 Lbs.
Height
8"
Width
14"
Depth
8 3/4"
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
