A New Generation of Rock Royalty

The new 3-channel, 50-watt, EL-34 powered Triple Crown™ 50 from MESA Engineering® captures the essence of Rock with the ability to inspire new genres in a way only MESA® can. Emanating from the “other side of MESA” that spawned Rock’s iconic Dual Rectifier®, this new platform features a bold set of new circuits unlike anything else in our line. From bubbly, sparkling clean sounds, rarely heard in this type of amp, to an amazingly tight and aggressive wall of Rock Crunch, to one of our most vocal, harmonically rich and gain-laden high-gain channels ever, the Triple Crown is aimed at Rock’s high-gain throne! Experience a new generation of Rock Royalty–The Triple Crown TC-50! YOUR CHOICE OF PUNCH. EL34, 6L6, OR 6V6 POWER Need versatility? The Triple Crown 50 features our handy BIAS SWITCH allowing you to swap the stock complement of EL34s with the fatter, rounder-sounding 6L6. For those who want a warmer, rounder response and more easily attainable power clip, 6V6s can also be used in the EL34 setting with a direct swap over, creating a “Half-Power” scenario that exudes a more bubbly, vintage voice and creamier top end harmonic content. LUSH REVERB, MIDI, DI WITH CAB SIMULATION AND MORE Our legendary lush all-tube Reverb drenches the Triple Crown 50’s three Channels with a beautiful 3-D halo and provides you with assignable choices on where to use it for the best results. Additional features include MIDI for true connectivity and a number of ways to access the amazing sounds and pro features in the Triple Crown 50. A STORE toggle switch allows simple one-touch writing of your footswitchable functions to any of 256 MIDI Program Numbers. There is also a MIDI Channel mini Rotary Selector for syncing of the MIDI Channel to be used by your controller of choice. The CabClone™ D.I., is featured as a convenient live or recording interface for direct input to a live or recording console (mixing board) without the need for a mic and you’ll find the full complement of voicing options have been included; CLOSED BACK, OPEN BACK and VINTAGE, for increased versatility and different sound styles. A HEADPHONE out feature allows for personal enjoyment of the amplifier when it is not possible or you simply prefer to play without a speaker. TIGHT, FAST ATTACK AND GUT-PUNCHING MIDS If you’re a fan of the work we do here at MESA, you’ve got to experience what we’ve captured in the new Triple Crown 50. Dressed in traditional design with a hint of modern style, get ready to experience the new generation of Rock Royalty– The Triple Crown 50! A new level of versatility delivered with an immediacy of attack and gut-punch midrange all its own in our line.

The new 3-channel, 50-watt, EL-34 powered Triple Crown™ 50 from MESA Engineering® captures the essence of Rock with the ability to inspire new genres in a way only MESA® can. Emanating from the “other side of MESA” that spawned Rock’s iconic Dual Rectifier®, this new platform features a bold set of new circuits unlike anything else in our line. From bubbly, sparkling clean sounds, rarely heard in this type of amp, to an amazingly tight and aggressive wall of Rock Crunch, to one of our most vocal, harmonically rich and gain-laden high-gain channels ever, the Triple Crown is aimed at Rock’s high-gain throne! Experience a new generation of Rock Royalty–The Triple Crown TC-50! YOUR CHOICE OF PUNCH. EL34, 6L6, OR 6V6 POWER Need versatility? The Triple Crown 50 feat . . .

{{guitar.Name}} Videos

{{activeVideo.Name}}

Wattage

50 Watts

Channels & Modes

3 Channels / 2 Modes per Channel

Mode Voicings styles

Ch. 1 = Normal (Clean) or Drive Ch. 2 = Normal (Modern Crunch) or Tight Ch. 3 = Normal (High-Gain) or Tight

Graphic Eq Reverb Fx Solo

Reverb, FX Loop, Solo

Foot switchable Functions

Ch. 1, 2, 3, Reverb, FX Loop & Solo

Speakers Impedance

n/a

Weight

25 Lbs.

Dimensions

7" H x 19" W x 9 1/2" D

Available Formats

Head, Rackmount & 1x12 Combo

Amp Type

Tube

Rectifier Type

Silicon Diodes

Rectifier Tubes

n/a

Variac PowerSwitch

n/a

Preamp Tubes

6x Mesa 12AX7, 1x Mesa 12AT7

Power Amp Tubes

2x Mesa EL-34 (or 6V6 or 6L6)

Maintenance Free Fixed Bias

Yes

Wattages Quick Reference

50 Watts

Built In Power Amp Attenuation

n/a

Power Amp Details Class Wattage

Class A/B Power for exceptional power, tight punch and clarity - Produces 50 Watts of power

Number Of Style Modes

Six

Number Of Style Modes Per Channel

Two

Channel Controls

Each Channel features Independent 2-Position Style Mode Switch, Gain, Treble, Mid, Bass, Presence, Reverb (back panel), and Master Controls

Graphic Eq And/or Contour

n/a

Reverb Effects Bypass Options

Footswitchable, All-Tube, Short-Tank Spring Reverb with Independent Channel Controls (rear panel)

Effects Loop Bypass Options

Footswitchable, Fully Buffered Series Tube FX Loop

Global Output Level Control

Yes (Over all channels)

Global Solo Level Control

Yes (Over all channels)

True Bypass Options

n/a

External Switching Jack Options And/or Midi

MIDI Switchable/Programmable via Control Change and Program Change messages, with 256 Preset Location (MIDI IN, MIDI Thru/Out, MIDI Channel & Store Switches) – Controls Channels 1, 2, 3, Reverb, FX Loop & Solo

Speaker Outputs

8 Ohm / 4 Ohm Switch with Two Speaker Jacks

Cabinet Simulation Direct Live recording Output

Built-in MESA CabClone™ Cab Simulator Output featuring Closed Back, Open Back & Vintage Cabinet Simulations, Internal Amp Load, Headphone Output & Uncompensated Line (Slave) Output, Speaker On/Off & Ground/Lift Switches

Internal Amp Load For SpeakerLess Performance

Yes (see Cabinet Simulation for more information)

Headphone Output

Yes (see Cabinet Simulation for more information)

Slave Output

Yes (Uncompensated Line Output works as Slave Out)

Extra Features

n/a

Footswitch

Included - 3x3 - 6 Button Footswitch (Bottom Row: Ch. 1, Ch. 2 & Ch. 3 - Top Row: Reverb, FX Loop & Solo)

Slip Cover

n/a

Cabinet Material

n/a

Standard Finish Options (No Extra Cost)

n/a

Custom Finish Options

n/a

Speakers Impedance

n/a

Casters

n/a

Extra Features

n/a

Weight

25 Lbs.

Height

7"

Width

19"

Depth

9 1/2"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
