{{ featureCallout.Title }}
Wattage
Multi-Soak™ 3, 7, 20, 50 or 100 Watts (Channel Assignable)
Channels & Modes
3 Channels / 2 Modes per Channel
Mode Voicings styles
Ch. 1 = Normal (Clean) or Drive Ch. 2 = Normal (Modern Crunch) or Tight Ch. 3 = Normal (High-Gain) or Tight
Graphic Eq Reverb Fx Solo
Reverb, FX Loop, Solo
Foot switchable Functions
Ch. 1, 2, 3, Reverb, FX Loop & Solo
Speakers Impedance
n/a
Weight
36 Lbs.
Dimensions
7 1/2" H x 19" W x 9 1/2" D
KEY NOT FOUND
Head & Rackmount (Requires 5 Spaces)
Amp Type
Tube
Rectifier Type
Silicon Diodes
Rectifier Tubes
n/a
Variac PowerSwitch
n/a
Preamp Tubes
6x Mesa 12AX7, 1x Mesa 12AT7
Power Amp Tubes
4x Mesa EL-34 (or 6V6 or 6L6)
Maintenance Free Fixed Bias
Yes
Wattages Quick Reference
3, 7, 20, 50 or 100 Watts via Mesa's Proprietary Multi-Soak™, Channel Assignable Power Attenuator - See Power Amp Details for more information
Built In Power Amp Attenuation
Built-in Mesa Multi-Soak™ Channel Assignable Power Attenuator - See Power Amp Details for more information
Power Amp Details Class Wattage
Class A/B Power with Mesa's proprietary Multi-Soak™ Channel Assignable Power Attenuator that provides each channel with an independent 5-position power switch with power choices of 3, 7, 20, 50 or 100 Watts per channel
Number Of Style Modes
Six
Number Of Style Modes Per Channel
Two
Channel Controls
Each Channel features Independent 2-Position Style Mode Switch, Gain, Treble, Mid, Bass, Presence, Reverb (back panel), Master & Multi-Soak Power Controls
Graphic Eq And/or Contour
n/a
Reverb Effects Bypass Options
Footswitchable, All-Tube, Short-Tank Spring Reverb with Independent Channel Controls (rear panel)
Effects Loop Bypass Options
Footswitchable, Fully Buffered Series Tube FX Loop
Global Output Level Control
Yes (Over all channels)
Global Solo Level Control
Yes (Over all channels)
True Bypass Options
n/a
External Switching Jack Options And/or Midi
MIDI Switchable/Programmable via Control Change and Program Change messages, with 256 Preset Location (MIDI IN, MIDI Thru/Out, MIDI Channel & Store Switches) – Controls Channels 1, 2, 3, Reverb, FX Loop & Solo
Speaker Outputs
8 Ohm / 4 Ohm Switch with Two Speaker Jacks
Cabinet Simulation Direct Live recording Output
Built-in MESA CabClone™ Cab Simulator Output featuring Closed Back, Open Back & Vintage Cabinet Simulations, Internal Amp Load, Headphone Output & Uncompensated Line (Slave) Output, Speaker On/Off & Ground/Lift Switches
Internal Amp Load For SpeakerLess Performance
Yes (see Cabinet Simulation for more information)
Headphone Output
Yes (see Cabinet Simulation for more information)
Slave Output
Yes (Uncompensated Line Output works as Slave Out)
Extra Features
n/a
Footswitch
Included - 3x3 - 6 Button Footswitch (Bottom Row: Ch. 1, Ch. 2 & Ch. 3 - Top Row: Reverb, FX Loop & Solo)
Slip Cover
n/a
Cabinet Material
n/a
KEY NOT FOUND
n/a
Custom Finish Options
n/a
Speakers Impedance
n/a
Casters
n/a
Extra Features
n/a
Weight
36 Lbs.
Height
7 1/2" (Requires 5 Rack Spaces)
Width
19"
Depth
9 1/2"
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
