{{ product.Name }} Videos

{{ activeVideo.Name }}

Preamp Type

Two Channels, Class A Vacuum Tube Preamps w/ 3x Mesa 12AT7

Wattage

800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms

Graphic Eq Reverb Fx Solo

Global: Deep Switch, Bright Switch Channel One – Boogie Channel features: Variable High-Pass Filter (25Hz – 125Hz) and Active Driven Passive 3-Band EQ (Bass, Mid with variable Mid-Shift Control, Treble) Channel Two – Subway Channel features: Variable High-Pass Filter (25Hz – 125Hz) and Fully Active 3-Band EQ (+/- 12dB of Bass, Mid & Treble) with Sweepable (variable) Mid Frequency Control (150Hz-2000Hz)

Foot switchable Functions

External Switching Jack for Channel Select & Tune/Mute (Footswitch Sold Separately)

Weight

7 lbs. 3.oz.

Dimensions

4" H x 12" W x 11.375" D

Available Formats

(Metal) Head - Rackmount Kit Optional

Amp Type

Tube Preamps & Class D Power Amp

Preamp Tubes

3x Mesa 12AT7

Power Amp Tubes

Class D Power Amp

Wattages Quick Reference

800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms

Power Amp Details Class Wattage

Light-Weight, Compact Class D Power Amp with Variable O/D Symmetry Control, Protection, Limit LED Indicators

Effects Loop Bypass Options

Two Fully Buffered, Channel Independant Series FX Loop

External Switching Jack Options And/or Midi

External Switching Jack for Channel Select & Tune/Mute (Footswitch Sold Separately)

Speaker Outputs

2 - Speakon Output Jacks (no 1/4" speaker jacks) - 8, 4 or 2 Ohms

Cabinet Simulation Direct Live recording Output

1x Tube-Driven, Post Master, Balanced XLR (DI) Out with Line/Mic & Ground Lift Switches / 1x Tube-Driven, Pre-EQ, Balanced XLR (DI) Out with Line/Mic & Ground Lift Switches

Slave Output

n/a

Extra Features

USB Power Outlet, Headphone Output and Auxiliary Input, Optional Two Space Rackmount Kit Available (sold separately)

Footswitch

Optional (Sold Separately) - 2 Button Channel Select & Tune/Mute Footswitch

Slip Cover

Included - Gig Bag with Shoulder Strap

Cabinet Material

n/a

Standard Finish Options (No Extra Cost)

n/a

Custom Finish Options

n/a

Speakers Impedance

n/a

Casters

n/a

Extra Features

n/a

Weight

7 lbs. 3.oz.

Height

4"

Width

12"

Depth

11.375"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
