{{ product.Name }} Videos

{{ activeVideo.Name }}

Preamp Type

2-Stage Class A Vacuum Tube Preamp w/ 1x Mesa 12AT7

Wattage

800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms

Graphic Eq Reverb Fx Solo

Variable High-Pass Filter (25Hz – 125Hz), Fully Active 5-Band EQ (+/- 12dB) featuring Bass, Treble and a selectable/bypassable 3-Band Semi-Parametric EQ Sweepable from 80Hz-1KHz, 150Hz-2.5KHz & 300Hz-5KHz respectively, and a Passive Mid Control

Foot switchable Functions

External Switching Jack for Parametric EQ & Mute (Footswitch Sold Separately)

Weight

7 Lbs.

Dimensions

4" H x 12" W x 11.375" D

Available Formats

(Metal) Head

Amp Type

Tube Preamp & Class D Power Amp

Preamp Tubes

1x Mesa 12AT7

Power Amp Tubes

Class D Power Amp

Wattages Quick Reference

800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms

Power Amp Details Class Wattage

Light-Weight, Compact Class D Power Amp with Variable Damping Control, Protection, Limit & 2-Ohm Load LED Indicators

Effects Loop Bypass Options

Fully Buffered Series FX Loop

External Switching Jack Options And/or Midi

External Switching Jack for Parametric EQ & Mute (Footswitch Sold Separately)

Speaker Outputs

2 - Speakon Output Jacks (no 1/4" speaker jacks) - 8, 4 or 2 Ohms

Cabinet Simulation Direct Live recording Output

Balanced XLR Out with Pre/Post, Line/Mic & Ground Lift Switches

Slave Output

n/a

Extra Features

USB Power Outlet, Headphone Output and Auxiliary Input

Footswitch

Optional (Sold Separately) - 2 Button Parametric EQ & Mute Footswitch

Slip Cover

Included - Gig Bag with Shoulder Strap

Cabinet Material

n/a

Standard Finish Options (No Extra Cost)

n/a

Custom Finish Options

n/a

Speakers Impedance

n/a

Casters

n/a

Extra Features

n/a

Weight

7 Lbs.

Height

4"

Width

12"

Depth

11.375"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
