Subway Bass DI-Preamp Box
The Tone and Features of Our Subway® D-800™ in a Bass DI Pedal
Combining the most important features of our SUBWAY® D800™ preamp with small size and convenient connectivity, the SUBWAY BASS DI creates our most compact Grab ‘N Go Bass solution. Switchable INPUT settings include PASSIVE and ACTIVE to handle both types of pickups optimally. Classic shelving-type Tone controls handle BASS and TREBLE and are joined by a Semi-Parametric MID Band to enable accurate shaping and/or enhancement of the midrange with a switchable DEEP mode to round out the voicing options. Balanced XLR PREAMP and DIRECT Outputs with a Pin 1 Lift feature for both and a PRE/POST SOURCE switch for the DIRECT Output to handle Stage and Front Of House duties while an UNBLANCED ¼” PREAMP OUT expands the interconnect possibilities even further. When you need great tone and flexibility on the Fly Dates, or simply back up standing ready in the Gig Bag, the SUBWAY BASS-DI offers maximum Tone for minimum carry.
Combining the most important features of our SUBWAY® D800™ preamp with small size and convenient connectivity, the SUBWAY BASS DI creates our most compact Grab ‘N Go Bass solution. Switchable INPUT settings include PASSIVE and ACTIVE to handle both types of pickups optimally. Classic shelving-type Tone controls handle BASS and TREBLE and are joined by a Semi-Parametric MID Band to enable accurate shaping and/or enhancement of the midrange with a switchable DEEP mode to round out the voicing options. Balanced XLR PREAMP and DIRECT Outputs with a Pin 1 Lift feature for both and a PRE/POST SOURCE switch for the DIRECT Output to handle Stage and Front Of House duties while an UNBLANCED ¼” PREAMP OUT expands the interconnect possibilities even further. When you need great t . . .
Preamp Type
Solid-State Preamp derived from Subway D-800
Graphic Eq Reverb Fx Solo
Variable Voicing (Flat to Vintage Scoop), Fully Active 4-Band EQ plus Deep Switch (for enhanced low-end)
Foot switchable Functions
n/a
Weight
1.26 Lbs.
Dimensions
2.51" H x 6.875" W x 5.27" D
Available Formats
D.I. Box Preamp
Preamp Type
Solid-State Preamp derived from Subway D-800
Preamp Tubes
n/a
Convention Or Fan Cooling
Convection
Number Of Channels & Input Options
1x 1/4" with Active/Passive Switch
Preamp Details
Solid-State Preamp featuring Input Gain, Variable Voicing (Flat to Vintage Scoop), Fully Active 4-Band EQ (+/- 12dB of Bass, Low-Mid, High-Mid, Treble) plus Deep Switch (for enhanced low-end) and Master Volume
Effects Loop
n/a
Boost (solo) Level Control
n/a
Output Options
Instrument-Thru Output, Balanced XLR Mic Level (DI) Out with Pre/Post & Ground Lift Switches, Line Level Preamp Outputs - Unbalanced & Balanced with Ground Lift Switch (drives any power amp)
Tuner Output/Mute
n/a
External Switching Jack Options
n/a
Extra Preamp Features
AC or Battery Powered, auto-switches to battery if AC fails and battery is installed
Footswitch
n/a
Slip Cover
n/a
Weight
1.26 Lbs.
Height
2.51"
Width
6.875"
Depth
5.27"
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
