Preamp Type

Solid-State Preamp derived from Subway D-800+

Graphic Eq Reverb Fx Solo

Variable High-Pass Filter (30Hz – 125Hz), Variable Voicing (Flat to Vintage Scoop), Fully Active 4-Band EQ (+/- 12dB of Bass, Low-Mid, High-Mid, Treble) with Sweepable (variable) Low-Mid (150Hz-1800Hz) & High-Mid (300Hz-5000Hz) Frequency Controls with Deep Switch (for enhanced low-end) & Bright Switch (for enhanced top-end)

Foot switchable Functions

Variable, Footswitchable Boost & Footswitchable Mute

Weight

2 Lbs.

Dimensions

2" H x 8" W x 5.5" D

Available Formats

D.I. Box Preamp

Preamp Type

Solid-State Preamp derived from Subway D-800+

Preamp Tubes

n/a

Convention Or Fan Cooling

Convection

Number Of Channels & Input Options

1x 1/4"

Preamp Details

Solid-State Preamp featuring Input Gain, Footswitchable Variable Boost, Variable High-Pass Filter (30Hz – 150Hz), Variable Voicing (Flat to Vintage Scoop), Fully Active 4-Band EQ (+/- 12dB of Bass, Low-Mid, High-Mid, Treble) with Sweepable (variable) Low-Mid (150Hz-1800Hz) & High-Mid (300Hz-5000Hz) Frequency Controls, Deep Switch (for enhanced low-end), Bright Switch (for enhanced top-end) and Master Volume

Effects Loop

Fully Buffered Series FX Loop

Boost (solo) Level Control

Variable, Footswitchable Boost

Output Options

Tuner Output, Balanced XLR Mic Level (DI) Out with Pre/Post & Ground Lift Switches, Line Level Preamp Outputs - Unbalanced & Balanced with Ground Lift Switch (drives any power amp), FX Loop Send (& Return)

Tuner Output/Mute

Tuner Output with Footswitchable Mute Switch

External Switching Jack Options

n/a

Extra Preamp Features

AC or Battery Powered, auto-switches to battery if AC fails and battery is installed

Footswitch

n/a

Slip Cover

n/a

Weight

2 Lbs.

Height

2"

Width

8"

Depth

5.5"

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
