Controls

Gain Control allows you to dial in the perfect amount of classic to modern high-gain, Lo/High Gain Switch provides classic crunch to modern meltdown, Master Level Control provides a variable range of signal boost up to +20dB, Tone Control balances the amount of high frequencies, Mid-Cut Control provides powerful mid-scoop for modern high-gain styles, Internal EQ-Boost Switch provides added style/voicing option

Switches

True Bypass On/Off Switching - Bypasses all circuitry when off to ensure no tonal loss,

Led Indicators

On/Off Status LED

Power Requirements

9V Battery Powered or optional AC Powered via External Power Jack Input. WARNING!!! To avoid immediate damage and voiding the warranty, the External Power Supply MUST be 9VDC with a NEGATIVE CENTER plug polarity and a jack plug size of 2.1mm x 5.5mm.

Current Draw

9VDC/15mA

Input Output Jacks

Input & Output Jacks (Nominal Input -20 db)

Input Impedance

1M Ohm (500k Ohm minimum)

Output Impedance

10k Ohm

Switching Type

True Bypass

Dimensions

4.77 x 2.87 x 2.30

Weight

0.865

Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
